Filling and Packing Machines / Metal Tanks / Water Treatment

GPK 60
GPK 120
GPK 140

Vertical Sachet Machines

Filling Heads

• Application

Small sachets with 3 or 4 sided seal.High volume production.Single sachets or strings.

• Function

Duplex horizontal form, fill & seal. [intermittent]

• Seal Type

Constant heat.

• Packaging Material

Single reel, heat sealable packaging material with registration mark or continuous print.

• Reel Dimensions

Diameter 350mm [max], width 260mm [max] Core diameter 65mm – 75mm

• Filling Options

Liquids, powders, granules, tablets.

• Filling Head Options

Auger fillerPiston fillerGear pumpTablet filling head

• Sachet SizeDuplex:

45mm [W] x 45mm [L] min 60mm [W] x 130mm [L] maxSimplex: 45mm
[W] x 45mm [L] min 120mm [W] x 130mm [L] max

• Filling Weight Duplex:

15g [max] / 18cc [max]Simplex: 45g [max] / 60cc [max]

• Speed Duplex:

160 sachets per minute [max]Simplex: 85 sachets per minute [max]Depending on sachet size, filling weight and packaging material.

• Machine Dimensions

2220mm [W] x 950mm [L] x 1750mm [H]
Machine Weight750kg [ approx]

• Electrical Requirements

380V 3ø, 15A

• Pneumatic Requirements

Depending on filling head option and machine extras

Noise Level Below 70dB

• Extras

Perforation, string application, vibrator, bottom seal, pneumatic notching, level control, Markem thermal transfer date coder, Stainless steel machine construction, wiring for multiple filling heads.

Liquid and Granual Fill
