Glopak - Filling and Packing Machines

GPM-A / Graphic Self-adhesive Labeling Machine

PLC control system, high-speed, operating using touch screen control.
Pneumatic printer system, printing the writing clear, fast, stable.
Roller bottles attached to the input, to make label attachment solid
Operation direction left or right - Labeling speed 30-200 pieces/min
The suitable length 1-100 mm. The suitable height 10-80 mm (Can be customized to actual situation)

GPLM-A / Print and Apply system

Machine details click here

GLM-A / Self adhesive label applicator

PLC control system, high-speed, operating using touch screen control.
Pneumatic printer system, printing the writing clear, fast, stable.
Roller bottles attached to the input, to make label attachment solid
Large scope of application, adapt to label various sizes of round bottles
Labeling speed - 30-300 pieces/min

GLB-510 Automatic round bottle labelling machine

Label width: 10-180mm
Product diameter: 20-100 , 25-150mm
Labelling speed: 50 -300 Bpm
Label length: 10-300mm
Reel Inner/Outer Diameter: 76mm/360mm(max)
Machine size: 1201L X 1070W X 1550H mm

GLM-D / Orientation round bottle labeling

PLC control system, so that the whole machine is stable, high-speed
Advanced servo control system, to enhance positioning accuracy
Operating system using touch-screen control, simple & efficient
Positioning type rotary bottle device, greatly improved labeling accuracy, apply to all bottle-type
Reciprocating cylinder positioning, can label the specified location accurately in the products
Labeling speed / 30 - 180 Bpm, +/- 1 mm label accuracy

GWM-A / Horizontal wrap-around labeler

PLC control system, stable at high-speed
Operating system using touch-screen control, simple and efficient
The advanced technology of penumatic coder system, so that the printed writing clear, fast and stable
Roll-bottle attached to lose, so that the labels attached to a more solid base
The rate of bottles damaged is less than 1/200,000
Large scope of application, adapted to label unbalanced round bottles with small diameter
Label Speed: 30-300 Bph / accuracy +/-1mm

GLM-A / Single label multi-surface labeler

PLC control system, stable at high-speed
Operating system using touch-screen control, simple and efficient
Multi-brush label device, can accomodate multi-faced labeling
Adjustment screw to suppress body movements accurately
Synchronization chain agencies, to ensure smooth and precise calibration
Label affixed to a transparent non-foaming
The use of a wide range of a multi-purepose machines and adaptable
Label speed: 20 - 120 Bpm / Accuracy +/- 1mm

CLM-A / Two-side labeler

PLC control system, stable at high-speed, Operating system using touch-screen control, simple, practical, efficient. Upgraded version of three-dimensional angle adjustment of the standard station design, may be adapted to tapered bottles. Imported servo control system can be chosen, which is stable and high-speed
Synchronization chain agencies, to ensure stable and accurate calibration
Labeling transparent labels without bubble and wrinkles
The use of a wide range of a multi-purpose machine and adaptabilty
Label speed: 50 - 180 Bpm, accuracy +/- 1mm

GFM-A / Carton corner sealing labeler

PLC control system, so that the whole stable, high-speed.
Operating system using touch-screen control, simple, practical, efficient.
Top pressure device to ensure stability of boxes when labeling and improve labeling accuracy effectively. It is particularly applicated for light and small boxes. Four kinds of corner sealing patterns: Two corners on the top side, two corners on the bottom side, and two diagonal corners.
Label speed: 30-200 Bpm / Highly accurate

GLB-220 Automatic top and bottom labeling machine

Label width: 10-120mm / 10-180
Product dia: 30-100 (bigger size is available on request)
Labelling speed: 50 - 200 Bpm
Label length: 10-300mm
Reel Inner/Outer Diameter: 76mm/360mm(max)
Machine size: 2750L X 1400W X 1665H mm

GLB-212 Online top labeler with stand

Label width: 10-120mm / 10-180mm
Label length: 10-250mm
Product dia: 15-160
Labelling speed: 50 - 250 Bpm

GLB-213 Side labeler with stand

Label width: 10-120mm / 10-180mm
Label length: 10-250mm
Product dia: 15-160
Labelling speed: 50 - 250 Bpm

GLB-6250 Automatic twin side labeling machine

Label width: 10-120mm / 10-180mm
Product dia: 30-100
Labelling speed: 50 - 200 Bpm
Label length: 10-250mm
Reel Inner/Outer Diameter: 76mm/360mm(max)
Machine size: 2750L X 1400W X 1665H mm

GLB-625 Automatic twin side positioning wrap-round labeller

Label width: 10-120mm / 10-180 / 10-220
Product dia: 30-100 (bigger size is available on request)
Labelling speed: 50 - 200 Bpm
Label length: 10-300mm
Reel Inner/Outer Diameter: 76mm/360mm(max)
Machine size: 2750L X 1400W X 1665H mm

ALP-100A / Automatic online pick and place labeler
