Horizontal Packaging Machines
kkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkkk
Product Description
Features
Dual frequency conversion control, bag length can be set and cut in one step to save time and film.
Interface features easy and quick for setting and operation.
Self failure diagnosis, clear failure display.
High sensitivity photoelectric eye colour tracing numerical input of cutting, sealing position for extra accuracy.
Positioned stop function without the knife sticking or wastage of film.
Temperature independent PID control, more suitable for packaging different materials.
Simple driving system, reliable working, convenient maintenance.
All the controls are computer driven making it easy for adjusting functions and technical upgrade.
Scope of application
Applicable to the pillow packaging of biscuit, instant noodle, ice cream, injector bearing etc, bar, block and round articles.
Technical Specification
Max width of packing film | =220mm |
Bag size | (50-165)×(30-100) ×(30-40)mm |
Packing speed | 30-200 bag/min |
Total power voltage | 220VAC - 50HZ |
Power | 2.75kw |
Size (lxWxH) | 1150×1795×11650 mm |
Weight | 550 Kg |
Optional collocate | Printer,Gas Charging device,Feeder,Tidier |
