GL-3B High speed dose filling machine

Designed for materials as powder and fine powder,this machine can finish, metering, filling, gas-flushing automatically.

Metering mode: Auger rotation filling
Packing weight: 100-3000g (The screw attachment is to be changed)
Packaging accuracy: = �0.3-1%
Filling rate: 25-110 bags/min
Power supply : 3P 380V/1P 220V 50~60HZ
Total power: 3KW
Total weight: 160kg
Electric equipment:servo drivers, plc control,transducer.....
Overall Dimensions: 1250�600�2000MM (without the auger)
Hopper volume: 110L

GL-3BL Mid-range dose filling machine

Designed for materials as powder and fine powder,this machine can finish, metering, filling, gas-flushing automatically.

Metering mode: Auger rotation filling
Packing weight: 100-3000g (The screw attachment is to be changed)
Packaging accuracy: =�0.3-1%
Filling rate: 20-80 bags/min
Power supply : 3P 380V/1P 220V 50~60HZ
Total power: 2.3KW
Total weight: 150kg
Electric equipment:servo drivers, plc control,transducer.....
Over dimension: 1030�690�1100MM
Hopper volume: 60L

GL-3B Mid-range dose filling machine

Designed for materials as powder and fine powder,this machine can finish, metering, filling, gas-flushing automatically.

Metering mode: Auger rotation filling
Packing weight: 10-1000g (The screw attachment is to be changed)
Packaging accuracy: = 100g, =�0.5~1g, >100g,=�0.5~1%
Filling rate: 10-100 bags/min
Cans supply:
Power supply : 3P 380V/1P 220V 50~60HZ
Total power: 1.2KW
Total weight: 130kg
Overall Dimensions: 540�790�1020MM
Hopper volume: 50L

GL-3AL Small dose filling machine

Designed for materials as powder and fine powder,this machine can finish, metering, filling, gas-flushing automatically.

Metering mode:auger rotation filling
Packing weight:1-500g(By changing auger)
Packing accuracy: =100g deviation=�0.5-1g ,
>100g deviation=�0.5-1%
Packing speed:20-80bags/min
Power supply:three-phase 380v(or customed single-phase 220v) 50-60Hz
Total power: 0.9KW Filling servo motor power750w Distortion distance2.39N.m ,stirerr servo motor power100w.
Overall dimensions: 510�585�930mm
Hopper size: 26L

GL-3A Small dose filling machine

Designed for materials as powder and fine powder,this machine can finish, metering, filling, gas-flushing automatically.

Metering mode:auger rotation filling
Packing weight:0.2-100g(By changing auger)
Packing accuracy: =�2%
Packing speed:10-100bags/min
Power supply:single-phase 220v 50-60Hz
Total power:0.5Kw stirrer power40w ,filling servo motor power400w,or filling stepping motor
Total weight:60KG
Overall dimensions: 330�450�530mm(except auger length)
Hopper size:10L
